12Vdc / 7...13,8Vdc / 92x92x38mm / 7,5W / 630mA / 6000Rpm / 130m³/h / 51dB / -20...70°C / IP20 / cl:B
Manufacturer | Ebmpapst |
Fan type | Compact |
Voltage | 12Vdc |
Dimensions | 92x92x38mm |
Power | 7,5w |
Bearing type | Ball bearing |
Speed | 6000rpm |
Air flow | 130m³/h |
Noise level | 51dB |
Protection class | IP20 |
Insulation class | B |
Connection line | 2 wires |
Operating temperature | -20...70°C |
Weight: 0.280  kg
Width: 9.2  cm
Height: 9.2  cm
Depth: 3.8  cm
