4212/12H

In stock

40,000 € Tax excluded

QuantityPriceYou Save
10 38,000 € Up to 20,000 €
20 35,200 € Up to 96,000 €

05215100

Ebmpapst

4212/12H - 12Vdc / 7-14,5Vdc / 120x120x38mm / 3 Fios / 4,3W / 440mA / 3050Rpm / 165m3/h./ 45dB / -20/+75ºC / IP20 / cl:B / Ventilador axial compacto de rolamentos / Sensor para monitorização da velocidade externa do ventilador - EBMPAPST
ManufacturerEbmpapst
Fan typeCompact
Voltage12Vdc
Dimensions120x120x38mm
Power4,3w
Bearing typeBall bearing
Speed3050rpm
Air flow165m³/h
Noise level45dB
Protection classIP20
Insulation classB
Connection line3 wires
Operating temperature-20...75°C
Weight: 0.250  kg
Width: 12.0  cm
Height: 12.0  cm
Depth: 3.8  cm
Datasheet (360.55k)

Write a review

4212/12H

4212/12H

12Vdc / 7...14,5Vdc / 120x120x38mm / 3Wires / 4,3W / 440mA / 3050Rpm / 165m³/h / 45dB / -20...75°C / IP20 / cl:B
