614NGH

In stock

28,000 € Tax excluded

QuantityPriceYou Save
10 26,600 € Up to 14,000 €
20 24,640 € Up to 67,200 €

05224250

Ebmpapst

614NGH - 24Vdc / 18-26Vdc / 60x60x25mm / 2,6W / 110mA / 5600Rpm / 46m3/h./ 38dB / -20/+70ºC / IP20 / cl:B / Ventilador axial compacto de chumaceiras - EBMPAPST
ManufacturerEbmpapst
Fan typeCompact
Voltage24Vdc
Dimensions60x60x25mm
Power2,6w
Bearing typeSlide bearing
Speed5600rpm
Air flow46m³/h
Noise level38dB
Protection classIP20
Insulation classB
Connection line2 wires
Operating temperature-20...70°C
Weight: 0.066  kg
Width: 6.0  cm
Height: 6.0  cm
Depth: 2.5  cm
Datasheet (1.52M)

Write a review

614NGH

614NGH

24Vdc / 18...26Vdc / 60x60x25mm / 2,6W / 110mA / 5600Rpm / 46m³/h / 38dB / -20...70°C / IP20 / cl:B
