R2D220-AA24-09

In stock

424,000 € Tax excluded

QuantityPriceYou Save
3 402,800 € Up to 63,600 €
6 373,120 € Up to 305,280 €

05451400

Ebmpapst

R2D220-AA24-09 - 400V/50Hz / 3 Fases - Estrela / 230V/50Hz / 3 Fases - Triângulo / 68W / 2450Rpm / 900m3/h. / -25/+55ºC / IP44 / cl:F / 221,4mm de diâmetro x 71mm altura máxima e 64,1 / 44mm altura da turbina / ventilador radial de rolamentos - EBMPAPST
ManufacturerEbmpapst
Fan typeRadial
Voltage400Vac, 230Vac
DimensionsØ221,4x67,4mm
Power68w
Speed2550rpm
Air flow900m³/h
Protection classIP44
Insulation classF
Connection line7 wires
Weight: 1.600  kg
Width: 22.1  cm
Height: 22.1  cm
Depth: 6.7  cm

Write a review

R2D220-AA24-09

R2D220-AA24-09

400V@50Hz / 230V@50Hz / 68W / 2550Rpm / 900m³/h / -40...80°C / IP44 / cl:F / Ø221,4x67,4mm
