SDR-120-24

In stock

64,000 € Tax excluded

QuantityPriceYou Save
5 60,800 € Up to 16,000 €
10 56,320 € Up to 76,800 €

24166460

Mean Well

SDR-120-24 / 5A - Fonte de alimentação comutada MEAN WELL / Tensão de entrada: 88 a 264Vac / 124 a 370Vdc / Tensão de saída: 24Vdc (24 a 28Vdc) / Corrente: 0 a 5A / Potência: 120W / Para calha DIN TS-35/7,5 ou 15
ManufacturerMean Well
Power supply type1 output
Power120w
Supply voltage (AC)88...264Vac
Supply voltage (DC)124...370Vdc
Output voltage24Vdc
Output voltage range24...28Vdc
Output current0...5A
Dimensions40x125.2x113,5mm
Operating temperature-25...70°C
Weight: 0.670  kg
Width: 12.5  cm
Height: 11.3  cm
Depth: 4.0  cm
Datasheet (431.27k)

Write a review

SDR-120-24

SDR-120-24

88...264Vac / 124...370Vdc / 24Vdc (24...28Vdc) / 0...5A / 120W / DIN TS-35 / 7,5 / 15
