90...264Vac / 127...370Vdc / 24Vdc (24...28Vdc) / 0...20A / 480W / DIN TS-35 / 7,5 / 15
Manufacturer | Mean Well |
Power supply type | 1 output |
Power | 480w |
Supply voltage (AC) | 90...264Vac |
Supply voltage (DC) | 127...370Vdc |
Output voltage | 24Vdc |
Output voltage range | 24...28Vdc |
Output current | 0...20A |
Dimensions | 85,5x125,2x128,5mm |
Operating temperature | -25...70°C |
Weight: 1.600  kg
Width: 12.8  cm
Height: 12.5  cm
Depth: 8.6  cm
